SAFETY | FIRE RATED - ONE WAY
1hr Fire Rated Anti-ligature Access Panel
1 Hour Fire Rated · Beaded Frame
Code:
ex VAT
Size (mm)
Popular sizes
Other sizes
Made-to-measure lead time:
—
For large orders, lead times may vary — please contact us to confirm.
Hinge side *
Calculated price (per unit)
—
Price = price/sqm × (W × H) area
· minimum £90.00
Lock
Save on volume
Ordering 50 or more? We'll prepare a project-specific quote with delivery scheduling and account terms.
Call 01937 325 325 →
14-day returns
Phone support 8–5 Mon–Fri
Trusted by specifiers since 2007
Datasheet
Technical specifications
Test Certificate
SAFETY | FIRE RATED - ONE WAY
Installation Guide
PDF instructions
Product details
- Anti-Ligature Steel Access Panel (Crucial Safety Feature)
- 1 Hour Fire Rated to BS 476 Part 22 (Walls and Ceilings)
- BS EN 1634-3 Smoke Test Approved (Up to 600x600mm)
- UKAS tested to provide 36dB acoustic reduction
- Picture and Beaded Frame options available
- Powder-coated finish in White (RAL9016)
- Fabricated from 0.9mm Zintec steel
- Part B and Part J compliant
Our Anti-Ligature Access Panel is engineered with specialised design features for use in safety-critical environments, providing certified fire resistance and controlled, one-way access.
Safety-Critical Application & Design:
• Purpose-Built Environments: Designed for installation in facilities where vulnerable occupants may be at risk, including hospitals, mental health facilities, correctional institutions, and similar secure premises.• Anti-Ligature Design Elements: Features design elements aimed at reducing potential ligature points. Available in both Picture Frame and Beaded Frame options to suit different finishing requirements.
• Fire Performance: The panel offers a certified One-Way Fire Rating, providing essential containment and safety integrity for service voids.
Installation & Access:
• Access Control: Engineered for One-Way access (typically secured from the service side), ensuring controlled entry to concealed building services.• Construction: Heavy-duty, robust construction suitable for challenging, high-traffic environments.
CRITICAL ANTI-LIGATURE DISCLAIMER
The anti-ligature design elements of this access panel are not intended to replace the need for necessary supervision of those who may be at risk, or for other mandatory protective measures. We do not offer any products for sale as being "ligature-free" and will not be liable for claims associated with ligature attachment on its hatches/panels.
Please Note: We can make this panel to custom dimensions.
*Hinged on the long edge.
| Code | Nominal Panel Size | Clear Opening (Once Installed) |
Depth |
|---|---|---|---|
| ANTILIG-BF-150 | 150x150mm | 80x75mm | 52mm |
| ANTILIG-BF-200 | 200x200mm | 140x120mm | 52mm |
| ANTILIG-BF-300 | 300x300mm | 264x220mm | 52mm |
| ANTILIG-BF-350 | 350x350mm | 314x270mm | 52mm |
| ANTILIG-BF-450 | 450x450mm | 412x370mm | 52mm |
| ANTILIG-BF-550 | 550x550mm | 514x470mm | 52mm |
| ANTILIG-BF-600X300 | 600x300mm* | 565x235mm | 52mm |
| ANTILIG-BF-600 | 600x600mm | 564x520mm | 52mm |
Specification
- Frame style
- Beaded Frame
- Fire rating
- 1 Hour Fire Rated
- Tested to
- BS 476 Part 22, in walls and ceilings
- Material
- Zintec Steel, white finish
- Frame width
- 25mm
- Wall or ceiling
- Both Wall & Ceiling
- Acoustic option
- 36dB Acoustic reduction
